RENTAL LGMG SR1623D DIESEL ROUGH TERRAIN SCISSOR LIFT

Rent the LGMG SR1623D diesel rough terrain scissor lift for demanding outdoor job sites. With a maximum working height of 17.9 m, 4×4 drive, auto-leveling outriggers, and a high-capacity platform, it is ideal for construction, MEP, and industrial maintenance across uneven ground.

Rental LGMG SR1623D Diesel Rough Terrain Scissor Lift

Description

SR1623D Diesel Rough Terrain Scissor Lift Rental

The LGMG SR1623D is a diesel-powered rough terrain scissor lift designed for reliable performance on uneven outdoor job sites. It is well-suited for construction projects, industrial plants, warehouses with external yards, and maintenance work where stable elevation and productive platform space are required.

Built for Outdoor Job Sites

With four-wheel drive, four-wheel braking, an oscillating axle, and auto-leveling outriggers, the SR1623D is engineered to handle challenging ground conditions while maintaining controlled movement and stable lifting. Proportional controls support smooth positioning at height for safer, more efficient work.

Productive Platform for Crews and Tools

The platform provides ample workspace for multiple operators and materials, supporting common tasks such as facade works, cladding, steel erection support, HVAC and electrical installations, piping, and general site maintenance. Extension deck options improve reach and reduce repositioning time.

Safety and Operator Support

Standard safety systems include tilt monitoring with lift cut-out, overload sensing, emergency stop, audible descent alarm with beacon, self-closing entry gate, and emergency descent provisions. On-board diagnostics and an hour meter support efficient fleet management and preventive maintenance.

Rental Support

We provide flexible rental terms for short-term and long-term projects, including delivery and collection to your site in Saudi Arabia. Contact us to confirm availability and the best configuration for your application.

Technical Specifications

Manufacturer

LGMG

Country of Origin

China

Model Number

SR1623D

Equipment Type

Diesel RT Scissor Lift

Working Height Max.

17.9 m

Platform Height - Raised

15.9 m

Platform Height - Stowed

2.08 m

Platform Length

3.98 m

Platform Width

1.83 m

Overall Length (with ladder)

4.9 m

Overall Width

2.3 m

Overall Height - Rails Up

3.18 m

Overall Height - Rails Down

2.5 m

Extension Deck (Front/Rear)

1.45/1.14 m

Wheelbase

2.85 m

Ground Clearance - Center

0.23 m

Platform Occupants Max. (in/out)

4/4

Platform Capacity

680 kg

Platform Capacity - Extension

230 kg

Drive Height

8.5 m

Gradeability - Stowed

40%

Turning Radius - Outside

5.33 m

Raise/Lower Speed

55/55 s

Brakes

Four-wheel brake

Drive Mode

4×4

Tires Type

Solid

Tires Size

835×290 mm

Power Source

Deutz D2.9 L4 36.4 kW / 48.8 hp

Fuel Tank Capacity

110 L

Hydraulic Oil Capacity

140 L

Machine Weight (6.58 m platform CE/ANSI)

8100 kg

Machine Weight (7.4 m platform CE/ANSI)

8200 kg

Standards Compliance

EN280; ANSI 92.20

Standard Features

Proportional control; Tilt alarm with lift cut-out; Overload sensing system; Descent alarm with flashing beacon; Self-lock entry gate; Auto-leveling outriggers; Emergency stop button; On-board diagnostic system; Oscillating axle; Four-wheel drive and brak

Optional Features

6.58 m / 7.4 m platform extension; AC power to platform; Platform anti-collision device; Hydraulic generator; Solid non-marking tires; Foam-filled tires; Foam-filled non-marking tires
